Name: China 100RV SP Vertical Cantilever Sump Pumps Price
Price: 8800.00 USD

China 100RV SP Vertical Cantilever Sump Pumps Price

Product Brands: Tobee

Tobee® 100RV-SP Vertical Spindle Pump is mainly used in a variety of sump conditions, It can also be readily applied on floating dewatering or other floating pump platforms. As a true cantilevered vertical slurry pump, TP100RV vertical spindle pump does not have submerged bearings or seals, thus, eliminating the primary failure mechanism for similarly fielded pump lines.

price:

$8800.00 $8830.00

Pump Type:

Vertical Slurry Pump SP vertical spindle pump SPR Vertical Sump Pump

Pump Models:

100RV-SP(R) 65QV-SP(R)

Quantity:

- + (44 available)

Add to Favorite Items (0)

Sales: 0+

Tobee® SP/SPR vertical slurry pumps, As a kind of heavy duty cantilever sump pump, it is designed for applications requiring greater reliability and durability than conventional vertical process pumps. Fully elastomer lined or hard metal fitted. No submerged bearings or packing. High capacity double suction design. Optional recessed impeller and suction agitator available.

100RV SP Vertical Sludge Pumps Design features:
1. Vertical sump pumps are vertical, centrifugal slurry pumps submerged in sump to work.
2. They are designed for delivering abrasive, large particle and high density slurries.
3. These pumps have no need of any shaft seal and sealing water.
4. They can also be operated normally for insufficient suction duties.
5. Wet parts of type SP metal vertical slurry pump are made of abrasion-resistant metal.
6. All parts of type SP(R) rubber lined vertical slurry pump immersed in liquid are lined with rubber outer liner. They are suited
7. To transport non-edge angle abrasive slurry.

100RV SP Metal Lined Vertical Slurry Pump Parts List:

No.	Pump Model	Part Name	Basic Part No.	Part Code	Material
1	100RV-SP	Bearing Housing	004	RV004-1	Ductile
2	100RV-SP	Bearing Sleeve	008	RV008	-
3	100RV-SP	Bearing	009	R009	SKF/Timken
4	100RV-SP	Bearing	009D	R009D-1	SKF/Timken
5	100RV-SP	Mounting Plate	019	RV10019	Steel
6	100RV-SP	End Cover	024	RV024	Ductile
7	100RV-SP	Low End Cover	024L	RV024L-1	Steel
8	100RV-SP	Key	-	RV070	Steel
9	100RV-SP	Washer	-	85	Steel
10	100RV-SP	Shim Set	025	RV025	-
11	100RV-SP	Nipple	-	M10X1	Steel
12	100RV-SP	Name Plate	-	-	-
13	100RV-SP	Rivet	-	-	Steel
14	100RV-SP	Back Liner	041	SP10041	Chrome alloy
15	100RV-SP	Suction Joint	060	SP10060	-
16	100RV-SP	Lock Nut	061	RV061	Steel
17	100RV-SP	Labyrinth	062	RV062	Steel
18	100RV-SP	Nipple 45	-	M10X1	Steel
19	100RV-SP	O Ring	064	RV064	Ductile
20	100RV-SP	Shaft	073	RV10073	Steel
21	100RV-SP	Shaft Sleeve Ejector	077	RV077	-
22	100RV-SP	Bearing Seal	089	RV089	-
23	100RV-SP	Casing	092	SP10092	Chrome alloy
24	100RV-SP	Column	102	RV10102	-
25	100RV-SP	Piston Ring	108	R108	Steel
26	100RV-SP	End Cover Set Screw	-	S027M	Steel
27	100RV-SP	Strainer	116	SP10116-1	-
28	100RV-SP	Lower Strainer	116L	SP10116L	D21
29	100RV-SP	Casing Seal	124	E4124	-
30	100RV-SP	Discharge Pipe	154	RV10154	-
31	100RV-SP	Flinger	184	RV-184-1	-
32	100RV-SP	Discharge Pipe Gasket	204	SP10204	-
33	100RV-SP	Impeller	206	SP10206	Chrome alloy
34	100RV-SP	O Ring	217	RV217	Steel
35	100RV-SP	Spacer Set	290	RV290	-
36	100RV-SP	Suction Pipe	322	SP10322	-

Label: 100RV SP vertical spindle pumps 100RV SPR vertical sump pump 65QV SP sump pumps and spares 150SV SP vertical pumps and parts China vertical submerged pumps and spares
