Name: Submersible Dredging Silt Sludge Pump with Agitator for Pumping Mud
Price: 3980.00 USD

Submersible Dredging Silt Sludge Pump with Agitator for Pumping Mud

Product Brands: Hydroman

Hydroman® Submersible Dredging Silt Sludge Pump is designed to handle wastewater with high levels of rags and other contaminations including solids, and submersible sludge sewage pumps are a commercial, heavy duty, top discharge, dewatering sump pump,ideally suited to troublesome slurry and sludge applications as well as agricultural waste, drainage projects and farm waste.

price:

$3980.00 $4260.00

Slurry Pump Type::

Submersible Mud Pump Submersible Sludge Pump

Theory:

Centrifugal Slurry Pump Submersible Pumps

H.S Code:

8413709990

Quantity:

- + (20 available)

Add to Favorite Items (0)

Sales: 0+

Hydroman^® Submersible Dredging Silt Sludge Pump Description:

Hydroman^® Submersible Dredging Silt Sludge Pump is designed to handle wastewater with high levels of rags and other contaminations including solids, and submersible sludge sewage pumps are a commercial, heavy duty, top discharge, dewatering sump pump,ideally suited to troublesome slurry and sludge applications as well as agricultural waste, drainage projects and farm waste. Submersible sludge pump fitted with an agitator, these models are designed to stir up mud and sand at the bottom and then discharge the water, mud and sand in suspension more effectively.

Submersible Dredging Silt Sludge Pump with Agitator for Pumping Mud

Hydroman^® Submersible Dredging Silt Sludge Pump Operating Conditions:

▪ Power Source: 380V/460V, 50/60Hz, 3 Phase.
▪ Max. Temperature of Liquid: 80℃
▪ Max. Concentration of Solids: should not exceed 70%, Max. specific gravity not more than 1.50
▪ Max. Submersed Depth: 80m (the motor must be submersed in liquid)
▪ The best installation is vertical, max. incline should not exceed 10°
Note:If operating condition is different than above, please specify with order

Hydroman^® Submersible Dredging Silt Sludge Pump Constructional Drawing:

Hydroman^® Submersible Dredging Silt Sludge Pump Performance Parameters:

No.	Model	Size (mm)	Capacity Q (m3/h)	Head H (m)	Power P (kw)	Eff. η （%）	Speed n (r/min)	Max. particles (mm)	Weight (kg)
1	100TJQ100-10-7.5	100	100	10	7.5	48	1460	21	220
2	100TJQ100-18-11	100	100	18	11	48	1460	21	240
3	100TJQ60-30-15	100	60	30	15	41	1460	13	265
4	100TJQ75-25-15	100	75	25	15	43	1460	13	260
5	100TJQ100-18-15	100	100	18	15	49	1460	21	270
6	100TJQ150-15-15	100	150	15	15	51	1460	21	270

Hydroman^® Submersible Dredging Silt Sludge Pump Applications:
