Tobee® Slurry Pump Stuffing Box Seal stayed between the stuffing box (078) and frame plate liner insert (041) for avoiding leak. Material for slurry pump seals is great significance to its sealing performance and service life, so Tobee can supply the slurry pump rubber seals in NBR, HNBR, SIL, VITON, FLS, EPDM, CR, IIR, ACM, NR etc. rubber material based on the different application. Tobee offered slurry pump rubber seals with the appropriate mechanical strength, including expansion strength, elongation tear resistance, and the slurry pump seals are not susceptible to corrosion, thus do not contaminate the medium.
Tobee® Slurry Pump Intake Joint is used for sealing the pump with inlet pipeline or inlet valve for preventing leak from suction end, It is installed on slurry pump suction flange.
Tobee® Slurry Pump Discharge Joint is used for sealing the pump with discharge pipeline or discharge valve for preventing leak from discharge end, It is installed on slurry pump discharge flange.
Tobee® Slurry Pump O-ring is designed for sealing two or more slurry pump parts during assembly, it is a loop of elastomer with a round cross-section. The O rings mainly are Bearing sealing ring (code 089), Impeller O ring (code 217), Shaft O ring (code 109).
Tobee® Slurry Pump Volute Seal is used for sealing volute liner with throatbush and frame plate liner insert, It is designed to prevent the liquids entering slurry pump chamber.
Tobee® Slurry Pump Rubber Seals Positions:
Tobee® Slurry Pump Rubber Parts Applications:
Tobee Slurry Pump Rubber Parts are widely used for AH/HH/L/M Horizontal slurry pumps, SPR Vertical rubber lined slurry pumps, Centrifugal horizontal slurry pumps, Warman rubber lined slurry pumps, Chemical slurry pumps, Silica sand slurry pumps, Minerals processing slurry pumps, De-Watering Screen Pump, Ore sand pumps, Tailings Pump, Pipe-jacking slurry pumps, Ball mill discharge Pump, Tunnelling slurry pumps, Mixing tank slurry Pump, Wet crushers slurry pumps, SAG mill discharge pumps, Ball mill discharge pumps, Rod mill discharge slurry pumps, Ni acid slurry pumps, Coarse sand pumps, Coarse tailings pumps, Phosphate matrix slurry pumps, Scrubber slurry Pump, Minerals concentrate pumps, Heavy media slurry pumps, Dredging Sand slurry pumps, Bottom ash slurry pumps, Fly ash pumps, Lime grinding pumps, Screen feed Pump, Oil sands pumps, Mineral Sands pumps, Fine tailings pumps, Tailings booster Pump, Thickner Tailings Pump, Process recycle Pump, Pipeline transfer pumps, Phosphoric acid slurry pumps, Coal slurry pumps, Flotation pumps.
