C2132XLP Slurry Pump Discharge Joint is installed on 3/2 C-AH Slurry Pumps.
Slurry Pump Discharge Joint Seal is one of rubber pump wet end parts which is used to seal the outlet of metal lined slurry pump for sealing slurry pump and pipeline or valve connected to the slurry pump discharge end.
Slurry Pump Discharge Joint made in rubber material like S01,S12,S42,R55,S31,S14,S10,S51 etc.
Slurry Pump Discharge Joint supplied by Tobee is suit: AH slurry pumps, L slurry pumps, M slurry pumps, HH slurry pumps, G and GH gravel sand pumps.
3/2 C-AH Slurry Pump Spare Parts List:
|
No. |
Pump Parts Name |
Pump Model |
Pump Part Code |
Matl. Code |
Unit Weight |
|
1 |
Adjust Screw |
3/2 C-AH |
C001 |
E62 |
|
|
2 |
Base |
3/2C-AH |
C003M |
G01 |
44.0 |
|
3 |
Bearing Assembly |
3/2C-AH |
C005M |
ZWZ Bearing |
33.0 |
|
4 |
Bearing Housing |
3/2C-AH |
C004M |
G01 |
15.0 |
|
5 |
Cover Plate |
3/2C-AH |
C2013 |
D21 |
24.0 |
|
6 |
Cover Plate Bolt |
3/2C-AH |
C015 |
E65 |
|
|
7 |
Cover Plate Liner |
3/2C-AH |
C2017 |
R55 |
4.0 |
|
8 |
Discharge Joint |
3/2C-AH |
C2132L |
S01 |
0.2 |
|
9 |
End Cover |
3/2C-AH |
C024 |
G01 |
1.4 |
|
10 |
Expeller |
3/2C-AH |
C028 |
A05 |
2.0 |
|
11 |
Expeller Ring |
3/2C-AH |
C029 |
A05 |
5.0 |
|
12 |
Expeller Ring |
3/2C-AH |
C029R |
R55 |
1.3 |
|
13 |
Frame Plate |
3/2C-AH |
C2032 |
D21 |
23.0 |
|
14 |
Frame Plate Bolt |
3/2C-AH |
D026 |
E62 |
|
|
15 |
Frame Plate Liner |
3/2C-AH |
C2036 |
R55 |
3.5 |
|
16 |
Frame Plate Liner Insert |
3/2C-AH |
C2041 |
A05 |
7.0 |
|
17 |
Frame Plate Stud |
3/2C-AH |
C039 |
E62 |
|
|
18 |
Gland |
3/2C-AH |
C044 |
G01 |
0.8 |
|
19 |
Gland |
3/2C-AH |
C044 |
C23 |
0.8 |
|
20 |
Gland Bolt |
3/2C-AH |
C045 |
C23 |
|
|
21 |
Grease Retainer |
3/2C-AH |
C046 |
G01 |
0.4 |
|
22 |
3/2C-AH |
C2147 |
A05 |
13.0 |
|
|
23 |
Impeller |
3/2C-AH |
C2127 |
R55 |
5.0 |
|
24 |
Intake Joint |
3/2C-AH |
C2060 |
S01 |
0.2 |
|
25 |
Labyrinth |
3/2C-AH |
G01 |
0.6 |
|
|
26 |
Labyrinth Locknut |
3/2C-AH |
C061 |
E62 |
0.2 |
|
27 |
Lantern Restrictor |
3/2C-AH |
C118 |
C23 |
0.3 |
|
28 |
Lantern Ring |
3/2C-AH |
C063 |
C23 |
0.2 |
|
29 |
Lip Seal |
3/2C-AH |
C090 |
S01 |
|
|
30 |
Neck Ring |
3/2C-AH |
C067 |
C23 |
0.044 |
|
31 |
O ring |
3/2C-AH |
B109 |
S10 |
|
|
32 |
O ring |
3/2C-AH |
C217 |
S10 |
|
|
33 |
O ring |
3/2C-AH |
C109 |
S10 |
|
|
34 |
Packing |
3/2C-AH |
C111 |
Q05 |
|
|
35 |
Packing |
3/2C-AH |
C111 |
Q21 |
|
|
36 |
Packing |
3/2C-AH |
C111 |
Q05A |
|
|
37 |
Packing |
3/2C-AH |
C111 |
X06 |
|
|
38 |
Piston Ring |
3/2C-AH |
C108 |
G01 |
|
|
39 |
Seal |
3/2C-AH |
C122 |
S01 |
0.1 |
|
40 |
Shaft |
3/2C-AH |
C073M |
E05 |
9.1 |
|
41 |
Shaft Sleeve |
3/2C-AH |
C075 |
C21 |
0.5 |
|
42 |
Shaft Sleeve |
3/2C-AH |
C075 |
C23 |
0.5 |
|
43 |
Shaft Sleeve |
3/2C-AH |
C075 |
J05 |
|
|
44 |
Shaft Sleeve |
3/2C-AH |
C076 |
C21 |
0.5 |
|
45 |
Shaft Sleeve |
3/2C-AH |
C076 |
C23 |
0.5 |
|
46 |
Shaft Sleeve |
3/2C-AH |
C076 |
J05 |
|
|
47 |
Shaft Spacer |
3/2C-AH |
C117 |
C21 |
0.3 |
|
48 |
Shaft Spacer |
3/2C-AH |
C117 |
C23 |
0.3 |
|
49 |
Shaft Spacer |
3/2C-AH |
C117 |
J05 |
|
|
50 |
Shaft Spacer |
3/2C-AH |
CAM117 |
C21 |
|
|
51 |
Shaft Spacer |
3/2C-AH |
CAM117 |
C23 |
|
|
52 |
Shaft Spacer |
3/2C-AH |
CAM117 |
J05 |
|
|
53 |
Shim Set |
3/2C-AH |
C025 |
P10 |
|
|
54 |
Stuffing Box |
3/2C-AH |
C078 |
A05 |
5.4 |
|
55 |
Volute Frame Seal |
3/2C-AH |
C2125 |
S01 |
0.03 |
|
56 |
Volute Liner |
3/2C-AH |
C2110 |
A05 |
29.0 |
