As a China-based slurry pump parts manufacturer, Tobee® provide a broad range of slurry pump rubber parts included rubber impellers, liners and plates, froth pump rubber parts, medium/light duty slurry pump rubber parts, sump pump rubber parts, FGD(flue gas desulfurization) pump rubber parts and customized rubber pump parts.
The rubber slurry pump parts are widely used in fine slurry conditions and lower PH to 2. Rubber pump parts are also many rubbers for different conditions, Tobee offers the full rubber pump parts including R08, R24, R26, R33, R38, R55, R66, S01, S10, S12, S21, S31, S42, S44, S50 etc.
Slurry Pump Parts List:
|
Basic Part Number |
Description |
Basic Part Number |
Description |
|
001 |
Adjusting Screw |
080 |
Stepped Washer |
|
003 |
081 |
Keeper Plate |
|
|
004 |
Bearing Housing |
083 |
|
|
005 |
085 |
Throatbush Cotter |
|
|
008 |
Bearing Sleeve |
089 |
|
|
009 |
Bearing |
090 |
Shaft Seal |
|
011 |
Clamp Washer |
092 |
Sump Pump Casing |
|
012 |
Clamp Bolt |
102 |
Sump Pump Column |
|
013 |
Cover Plate |
108 |
Piston Ring |
|
015 |
Cover Plate Bolt |
109 |
Shaft Sleeve O-Ring |
|
017 |
Cover Plate Liner |
110 |
|
|
018 |
Cover Plate Liner – Throatbush |
111 |
|
|
019 |
Sump Pump Mounting Plate |
112 |
Throatbush |
|
021 |
Impeller – Two Vanes Open |
114 |
Impeller – Six Vanes Open |
|
023 |
Cover Plate Liner Stud |
116 |
Sump Pump Strainer |
|
024 |
End Cover |
117 |
Shaft Spacer |
|
025 |
End Cover Shim |
118 |
Lantern Restrictor |
|
026 |
Frame Plate Liner Stud |
122 |
Seal Ring |
|
027 |
End Cover Set Screw |
124 |
Volute Cover Seal |
|
028 |
125 |
Volute Frame Seal |
|
|
029 |
126 |
Gland Clamp Bolt |
|
|
032 |
127 |
Impeller – Five Vanes Open |
|
|
034 |
Frame Plate Bolt |
130 |
Flange |
|
036 |
Frame Plate Liner |
131 |
Gravel Pump Bowl |
|
039 |
Frame Plate Liner Stud |
132 |
Discharge Joint Ring |
|
040 |
Frame Plate Liner Insert Bolt |
134 |
Clamp Ring |
|
041 |
135 |
Clamp Ring |
|
|
043 |
Frame Plate Liner |
137 |
Impeller – Three Vanes Closed |
|
044 |
Gland |
138 |
Grease Cup Adaptor |
|
045 |
Gland Bolt |
143 |
Volute Seal Holder |
|
046 |
Grease Retainer |
144 |
Volute Seal Holder Stud |
|
049 |
Impeller – Eight Vanes Closed |
145 |
Impeller – Four Vanes Closed |
|
051 |
Impeller – Two Vanes Open |
147 |
|
|
052 |
Impeller – Three Vanes Open |
154 |
Sump Pump Discharge Pipe |
|
053 |
Impeller – Eight Vanes Open |
179 |
Shaft Sleeve Spacer |
|
056 |
Impeller – Four Vanes Open |
184 |
Sump Pump Flinger |
|
058 |
Impeller – Six Vanes Closed |
190 |
Suction Cover |
|
060 |
Intake Joint Ring |
191 |
Impeller – Eight Vanes Open |
|
061 |
Labyrinth Locknut |
204 |
Discharge Joint |
|
062 |
Labyrinth |
206 |
Sump Pump Impeller |
|
063 |
Lantern Ring |
217 |
Impeller O-Ring |
|
064 |
Impeller Sealing O-Ring |
221 |
Flange |
|
066 |
Motor Support Bolt |
239 |
Release Collar |
|
067 |
Neck Ring |
241 |
Lip Seal Gland |
|
070 |
Shaft Key |
290 |
Sump Pump Spacer |
|
073 |
Shaft |
292 |
Door Clamp Plate |
|
075 |
Shaft Sleeve |
322 |
Sump Pump Suction Pipe |
|
076 |
Shaft Sleeve – Long Type |
360 |
Mechanical Seal Adaptor |
|
078 |
Stuffing Box |
424 |
Mechanical Seal Shaft sleeve |
|
079 |
Expeller Ring Stud |
|
|
