Tobee are a professional China slurry pump parts manufacturer, Slurry Pump spare parts are a maintenance requirement when operating slurry pumps, and can’t be ignored. Tobee offer suitable replace spare parts for original slurry pump,including heavy duty slurry pumps AH (R), M (R), high head slurry pump HH, light duty slurry pump L (R), gravel pumps, sump pump, and froth pump. Tobee have different materials, such as high chrome pump parts, dual-phase steel slurry pump parts, slurry rubber pump spares, polyurethane pump spare parts, slurry pump ceramic sapres, etc.
High chrome slurry pump parts are made of 27-28% high chrome metallurgy has a guaranteed HRC63+ hardness. Variety of metallurgies are available for more corrosive applications.
Rubber slurry pump wearing parts are designed to provide longer life and abrasion resistance in a variety of applications. Now natural rubber and synthetic elastomers are majority material of slurry wetted parts.
Ceramic slurry pump spare parts are made of Silicon Nitride Bonded Silicon Carbide, aimed to Wear and Erosion resistant working application, such as coal power generation, non-ferrous foundry, mining and etc.
Polyurethane pump wearing spares are an erosion resistant material that performs well in elastomer applications where ‘tramp’ is a problem. This is attributed to the high tear and tensile strength of Polyurethane.
|
Basic Part Number |
Description |
Basic Part Number |
Description |
|
001 |
Adjusting Screw |
080 |
Stepped Washer |
|
003 |
081 |
Keeper Plate |
|
|
004 |
Bearing Housing |
083 |
|
|
005 |
085 |
Throatbush Cotter |
|
|
008 |
Bearing Sleeve |
089 |
|
|
009 |
Bearing |
090 |
Shaft Seal |
|
011 |
Clamp Washer |
092 |
Sump Pump Casing |
|
012 |
Clamp Bolt |
102 |
Sump Pump Column |
|
013 |
Cover Plate |
108 |
Piston Ring |
|
015 |
Cover Plate Bolt |
109 |
Shaft Sleeve O-Ring |
|
017 |
Cover Plate Liner |
110 |
|
|
018 |
Cover Plate Liner – Throatbush |
111 |
|
|
019 |
Sump Pump Mounting Plate |
112 |
Throatbush |
|
021 |
Impeller – Two Vanes Open |
114 |
Impeller – Six Vanes Open |
|
023 |
Cover Plate Liner Stud |
116 |
Sump Pump Strainer |
|
024 |
End Cover |
117 |
Shaft Spacer |
|
025 |
End Cover Shim |
118 |
Lantern Restrictor |
|
026 |
Frame Plate Liner Stud |
122 |
Seal Ring |
|
027 |
End Cover Set Screw |
124 |
Volute Cover Seal |
|
028 |
125 |
Volute Frame Seal |
|
|
029 |
126 |
Gland Clamp Bolt |
|
|
032 |
127 |
Impeller – Five Vanes Open |
|
|
034 |
Frame Plate Bolt |
130 |
Flange |
|
036 |
Frame Plate Liner |
131 |
Gravel Pump Bowl |
|
039 |
Frame Plate Liner Stud |
132 |
Discharge Joint Ring |
|
040 |
Frame Plate Liner Insert Bolt |
134 |
Clamp Ring |
|
041 |
135 |
Clamp Ring |
|
|
043 |
Frame Plate Liner |
137 |
Impeller – Three Vanes Closed |
|
044 |
Gland |
138 |
Grease Cup Adaptor |
|
045 |
Gland Bolt |
143 |
Volute Seal Holder |
|
046 |
Grease Retainer |
144 |
Volute Seal Holder Stud |
|
049 |
Impeller – Eight Vanes Closed |
145 |
Impeller – Four Vanes Closed |
|
051 |
Impeller – Two Vanes Open |
147 |
|
|
052 |
Impeller – Three Vanes Open |
154 |
Sump Pump Discharge Pipe |
|
053 |
Impeller – Eight Vanes Open |
179 |
Shaft Sleeve Spacer |
|
056 |
Impeller – Four Vanes Open |
184 |
Sump Pump Flinger |
|
058 |
Impeller – Six Vanes Closed |
190 |
Suction Cover |
|
060 |
Intake Joint Ring |
191 |
Impeller – Eight Vanes Open |
|
061 |
Labyrinth Locknut |
204 |
Discharge Joint |
|
062 |
Labyrinth |
206 |
Sump Pump Impeller |
|
063 |
Lantern Ring |
217 |
Impeller O-Ring |
|
064 |
Impeller Sealing O-Ring |
221 |
Flange |
|
066 |
Motor Support Bolt |
239 |
Release Collar |
|
067 |
Neck Ring |
241 |
Lip Seal Gland |
|
070 |
Shaft Key |
290 |
Sump Pump Spacer |
|
073 |
Shaft |
292 |
Door Clamp Plate |
|
075 |
Shaft Sleeve |
322 |
Sump Pump Suction Pipe |
|
076 |
Shaft Sleeve – Long Type |
360 |
Mechanical Seal Adaptor |
|
078 |
Stuffing Box |
424 |
Mechanical Seal Shaft sleeve |
|
079 |
Expeller Ring Stud |
|
|
