Pump Spares Australia are a maintenance requirement when operating slurry pumps, and can’t be ignored. Tobee offer suitable replace pump wearing parts for original slurry pump,including heavy duty slurry pumps AH (R), M (R), high head slurry pump HH, light duty slurry pump L (R), gravel pumps, sump pump, and froth pump.
High chrome slurry pump parts are made of 27-28% high chrome metallurgy has a guaranteed HRC62+ hardness. Variety of metallurgies are available for more corrosive applications.
Rubber slurry pump wearing parts are designed to provide longer life and abrasion resistance in a variety of applications. Now natural rubber and synthetic elastomers are majority material of slurry wetted parts.
Ceramic slurry pump spare parts are made of Silicon Nitride Bonded Silicon Carbide, aimed to Wear and Erosion resistant working application, such as coal power generation, non-ferrous foundry, mining and etc.
Polyurethane pump wearing spares are an erosion resistant material that performs well in elastomer applications where ‘tramp’ is a problem. This is attributed to the high tear and tensile strength of Polyurethane.
Tobee® Slurry Pump Spares Features:
1. All the spares can be changeable with original slurry pump. the pump wetted parts’ material can be optional as metal, rubber, or ceramic according to customer’s requirement.
2. Bearing assembly – a large diameter shaft with short overhang minimizes deflection and contributes to long bearing life. Only four through bolts are required to hold the cartridge type housing in the frame.
3. Volute Liners of Slurry Pump – easily replaceable liners are bolted, not glued, to the casing for positive attachment and east of maintenance. Hard metal liners are completely interchangeable with pressure moulded elastomer.
4. Elastomer seal rings back all liner joints.
5. Pump casing – Casing halves of cast or ductile iron with external reinforcing ribs provide high operating pressure capabilities and an extra measure of safety.
6. Slurry Pump Impeller–front and rear shrouds have pump out vanes that reduce recirculation and seal contamination. Hard metal and moulded elastomer impellers are completely interchangeable.
7. CNC machining impeller threads require no inserts or nuts. High efficiency and high head designs are also available.
8. Throatbush – wear is reduced and maintenance simplified by the use of tapered mating faces to allow positive accurate alignment during assembly and simple removal.
9. One-piece frame – a very robust one-piece frame cradles the cartridge type bearing and shaft assembly.
10. An external impeller adjustment mechanism is provided below the bearing housing for easy adjustment of impeller clearance.
11. Pump exit position- Based on 45 degree interval, rotating eight different angles of installation.
