Name: Hydraulic Submersible Slurry Pump
Price: 24570.00 USD

Hydraulic Submersible Slurry Pump

Product Brands: Hydroman

Hydraulic Submersible Slurry Pump are specialized for those circumstances that are difficulty to dig, such as much more water and watery sludge and sand. Remove the bucket and connect to the hydraulic mortar pump, concentration of extraction with high efficient and density could be achieved.

price:

$24570.00 $25865.00

Pump Type:

Submersible Slurry Pump Hydraulic Slurry Pump

Drive Type:

Hyraulic Power

Seal Arrangement:

Double mechanical seal

Certificates:

ISO CE SGS EAC

Quantity:

- + (10 available)

Add to Favorite Items (0)

Sales: 0+

Hydroman™ Hydraulic Submersible Slurry Pump is protected by a mechanical seal, which can effectively prevent high-pressure water and impurities. In addition to the main impeller, there is also an agitating impeller for the submersible slurry pump, which can agitate the slag deposited on the bottom of the water. Plus, the mixing impeller and other main flow parts are made of advanced materials, which are wear-resistant, corrosion-resistant, non-clogging, strong in sewage, and can effectively pass larger solid particles.The slag suction efficiency is high, and the dredging is more thorough. The motor of submersible slurry pumps dives into the water, without the need to construct complex ground protection and fixing devices, and the management is easier, thus to ensure high and reliable performance.

Hydroman™ Hydraulic Submersible Slurry Pump Features：

1. The hydraulic submersible mud slurry pump has better stability and longer life span, because the main parts are made of abrasion resistant materials – Hyperchrome alloy.

2. Unique mechanical seal device can prevent the electric motor from high pressure water and impurities, then high suction efficiency of hydraulic submersible mud pump can be ensured.

3. Except for the main impeller inner submersible slurry mud pump, there is extra agitation impeller at bottom to cut and mix the sludge, so the efficiency will be improved more.

4. The hydraulic submersible mud pump is easy to installation and operate while without additional vacuum pump or pump house.

5. The submersible mud pump is high efficient and enery-saving due to the powerful bottom agitator.

6. Professional technology support is provided for the whole process of the usage and maintenance.

Hydroman™ Hydraulic Submersible Slurry Pump Performance Parameters:

No	Hydraulic Dredge Pump						Hydraulic motor
No	Model	Size (mm)	Capacity Q (m3/h)	Head H (m)	Power P(kw)	Granularity (mm)	Output	Pressure	Capacity
1	100TQSY100-10	100	100	10	7.5	25	32	25	48
2	80TQSY50-22	80	50	22	7.5	20
3	80TQSY50-26	80	50	26	11	20
4	100TQSY80-22	100	80	22	11	25
5	100TQSY130-15	100	130	15	11	25
6	100TQSY60-35	100	60	35	15	25	40	25	60
7	100TQSY100-28	100	100	28	15	25
8	150TQSY150-15	150	150	15	15	30
9	100TQSY100-35	100	100	35	22	25	50	25	75
10	100TQSY130-30	100	130	30	22	25
11	150TQSY150-22	150	150	22	22	30
12	150TQSY200-15	150	200	15	22	35
13	150TQSY240-10	150	240	10	22	35
14	100TQSY150-35	100	150	35	30	25	80	20	120
15	150TQSY180-30	150	180	30	30	30
16	150TQSY240-20	150	240	20	30	35
17	200TQSY300-15	200	300	15	30	35
18	150TQSY280-20	200	280	20	37	35
19	200TQSY350-15	200	350	15	37	35
20	150TQSY200-30	150	200	30	45	30	112	27.5	168
21	200TQSY350-20	200	350	20	45	40
22	200TQSY400-15	200	400	15	45	40
23	150TQSY240-35	150	240	35	55	30
24	200TQSY300-24	200	300	24	55	40
25	250TQSY500-15	250	500	15	55	45
26	150TQSY240-45	150	240	45	75	35	125	28	188
27	200TQSY350-35	200	350	35	75	45
28	250TQSY500-20	200	500	20	75	46
29	200TQSY400-40	200	400	40	90	45	160	27	240
30	250TQSY550-25	200	550	25	90	45
31	300TQSY660-30	300	660	30	110	50
32	300TQSY800-22	300	800	22	110	50
33	250TQSY500-45	300	500	45	132	50	200	27.5	300
34	300TQSY700-35	300	700	35	132	50	200	27.5	300

Label: Hydraulic Submersible Slurry Pump Hydraulic Submersible Dredging Sand Pump Hydraulic Engine Driven Submersible Sand Pump Submersible Hydraulic Slurry Pump Submersible Hydraulic Drive Sand Pump
