Hydroman® Hydraulic Submersible Mud Dewatering Pump Description:
Hydroman® Hydraulic Submersible Mud Dewatering Pump is a hydraulic machine with agitation function, The THY hydraulic pump has excellent material selection, advanced structure and strong passing ability. It is suitable for the medium with variable size of solid in sediment, cinder, tailings, ore etc., mainly used in metallurgy, mining, thermal power plants, steel, water treatment, sand mining, mining, ports, rivers, lakes, ponds and dredging; suction and transport for the sediment medium such as port construction and river beach filling, Hydroman® hydraulic slurry pump is a great replacement of the traditional slurry pump. The complete equipment can be flexibly matched with other equipment, Like Hydraulic Oil Unit, Excavator, Loading machine and etc.. Breaking power restrictions, flexible transitions, especially in remote areas.
Hydroman® Hydraulic Submersible Mud Dewatering Pump Benefits:
▪ High performance in heavy duty conditions - Hydroman® submersible pumps ensure transportation up to 35% of dry mass (sand, gravel etc.) from total pump capacity.
▪ Oversized motors are designed for sludge and slurries with solid concentration up to 70% by weight and 1.6 Kg/dm3. The hydraulic drive version is also available to provide higher performance in especially harsh working conditions.
▪ Advanced mixing and excavating movement is created by HI-CR steel agitator cutter blades. The agitator lifts and sucks settled sediments of solids, creating a continous flow of concentrated slurry into the pump.
▪ Additional hydraulic excavators can be connected directly to the pump for extra digging support in hard-packed sand and clay.
▪ Low operating costs. Lower speed (rotations) ensures lower wear and long life of components. For example, model THY220A/B pump works at amazingly low operating speed of only 600 rev/min.
▪ Abrasion resistance, long service life and reliability guaranteed by the rugged and heavy construction. Extra strong wear parts produced in Hyperchrome are resistant to highly abrasive particles and provide longer life between spare parts replacements.
Hydroman® Hydraulic Submersible Mud Dewatering Pump Applications:
▪ Waste sludge handling / Tank clean out / Waste collection ponds / Thickener clean out / Barge unloading.
▪ Waste collection pit / Ash sumps / Dredging waste ponds / Bark Collection pit / Clean up sumps.
▪ Gold tailings reclamation / Ball mill sumps / Settling and collection ponds / Underground slimes collection ponds / Conveyor tunnel sumps / Tailings back-fill system / Preparation plant collection sumps / Coal tailings relocation / Open pit slimes removal / Crusher sumps / Grinding area sumps / Flotation area sumps / Removal of material of material from thickeners / Truck wash sumps.
▪ Mill scale pits / Coke plant scale pit / boast furnace slag pit / Water treatment sumps / Clean up sumps.
▪ Dredging deep deposits (up to 120 m deep) / Recovery of sand not mined by primary dredge / Sands mining.
▪ Trench clean out and back-fill in pipe-cable laying projects / Clean out caissons in construction / Transfer of bentonite slurry / Overburden removal / Silt from gravel washing.
▪ Removal of silt build up at marinas, harbors, dock loading facilities, etc. / Clean out of contaminated sludge collection ponds / Reclaiming beaches / River, lake and canal clean out. De-silting water intakes / Emergency dump pond / Ash decant sumps / Fly ash collection sump / Ash and waste collection pit / Scrubber sludge transfer / Lime collection pit / Coal wash-down sumps.
▪ Coke conveyor spillage sumps / Crude oil tank clean out / Sludge transfer / Settling-collection pits / Tailings recovery / Coke fines collection pit / Relocation of sand filled drilling rigs / Drilling mud barge unloading.
▪ Pumping marble dust.
