Name: FAM12147A05 Impeller for 14/12F-AH Slurry Pump
Price: 9000.00 USD

FAM12147A05 Impeller for 14/12F-AH Slurry Pump

Product Brands: Tobee

High chrome Cr27.5 pump impellers replacement Warman 14/12F-AH Heavy Duty Slurry Pump impellers

price:

$9000.00

Materials:

A05 A07 A33 A49 A61

Parts Code:

FAM12147A05

Pump model:

14/12F-AH

Quantity:

- + (60 available)

Add to Favorite Items (0)

Sales: 0+

FAM12147A05 High Chrome Impeller is the most important wearing parts for 14/12F-AH Horizontal Slurry Pumps.

Tobee® Horizontal Slurry Pump Impellers: GAM14147 high chrome impellers, G12147 high chrome impellers, FAM12147 high chrome impellers, G10147 high chrome impellers, G8147 high chrome impellers, FAM8147 high chrome impellers, F6147 high chrome impellers, E4147 high chrome impellers, D3147 high chrome impellers, C2147 high chrome impellers, B15127 high chrome impellers, B1127 high chrome impellers for AH Slurry pumps.

The Slurry pump impeller is one of the most important parts of your centrifugal slurry pumps. Depending on your application, Slurry pump impeller selection can be crucial to slurry pump performance. Slurry applications can be especially hard on the impeller of your slurry pump because of their abrasive nature. In order for your process to operate efficiently and stand up to the test of time, you must choose the proper impeller for your slurry pumps.

For the chrome alloy impeller, the standard is High chrome Alloy(27% Cr), it can be used from PH 5 to 12, and its hardness can be to HRC65, which is a very good choice for slurry control and transport. But in some conditions, the PH may lower than 5, then we try to use A49, it can lower to PH4, mostly used in FGD processing, Tobee offers the full impellers including A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61 etc.

Slurry Pump Impeller Benefits:
• Increased wear life – Tobee slurry pump wear parts is designed to increase wear life between 30% and 50%
• Power savings – lower pump power consumption
• Cost reduction – higher pump efficiency sustained over a longer pumping operation time
• Retrofit – new high abrasion resistance slurry pump wear parts retrofit to your current slurry pumps
• Lower NPSH requirements – results in enhanced hydraulic performance and extended wear life

Slurry Pump Impellers List:

Impeller Code	AH Slurry Pump	Slurry Pump Materials Code
B1127	1.5/1B-AH	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
B15127	2/1.5B-AH	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
C2147	3/2C-AH	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
C2127	3/2C-AH	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
C2051	3/2C-AH	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
D3147	4/3C-AH, 4/3D-AH	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
D3145HE1	4/3C-AH, 4/3D-AH	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
D3021	4/3C-AH, 4/3D-AH	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
E4147	6/4D-AH, 6/4E-AH	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
E4056	6/4D-AH, 6/4E-AH	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
E4058	6/4D-AH, 6/4E-AH	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
F6147	8/6E-AH, 8/6F-AH, 8/6R-AH	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
F6056	8/6E-AH, 8/6F-AH, 8/6R-AH	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
F6021	8/6E-AH, 8/6F-AH, 8/6R-AH	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
F6058HE1	8/6E-AH, 8/6F-AH, 8/6R-AH	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
FAM8147	10/8F-AH	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
G8147	10/8ST-AH	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
FAM10147	12/10F-AH	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
G10147	12/10ST-AH	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
FAM12147	14/12F-AH	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
G12147	14/12ST-AH	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
GAM14147	16/14TU-AH	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
Impeller Code	L Slurry Pump	Slurry Pump Materials Code
175056	20A-L	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
32056	50B-L	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
43056	75C-L	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
64056	100D-L	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
86056	150E-L	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
108056	200E-L	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
SL30147	300S-L	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
SL35147	350S-L	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
STL40147	400ST-L	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
STL45147	450ST-L	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
TUL55147	550TU-L	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
Impeller Code	M Slurry Pump	Slurry Pump Materials Code
F8147	10/8E-M, 10/8F-M, 10/8R-M	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
F10147	12/10F-M, 12/10R-M	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
Impeller Code	HH Slurry Pump	Materials
CH1127	1.5/1C-HH	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
DH2147	3/2D-HH	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
EH3147	4/3E-HH	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
FH4147	6/4F-HH	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
FH6147	6S-H, 8/6S-H	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
Impeller Code	G(H) Gravel Pump	Slurry Pump Materials Code
DG4137	6/4D-G, 6/4E-G	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
EG6137	8/6E-G	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
FG8137	10/8F-G, 10/8S-G	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
FG10137	12/10G-G	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
GG12137	14/12G-G	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
FGH8137	10/8F-GH	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
GGH10137	12/10G-GH	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
TG14148	16/14TU-GH	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
Impeller Code	SP Vertical Slurry Pump	Slurry Pump Materials Code
SP4206	40PV-SP	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
SP65206	65QV-SP	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
SP10206	100RV-SP	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
SP15206	150SV-SP	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
SP20206	200SV-SP	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
SP25206	250TV-SP	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61
SP30206	300TV-SP	A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61

Label: FAM12147A05 impeller work wheelFAM12147A05 replacement warman spare parts
