Tobee® 4/3C-AHR Rubber lined Slurry Pump is widely used for transporting slurry with strong corrosion and high concentration for many industries such as metallurgy, mine, coal, electric power, building materials etc. The wet parts is 100% interchangeable with 4/3C-AH metal lined slurry pump.
Tobee® 4/3 C-AHR Slurry Pump Design Features:
Type 4/3 C-AHR Slurry Pump are cantilevered, horizontal, centrifugal slurry pump. They are designed for the handing high density slurries in the metallurgical, mining , coal, power, building material and other industrial department etc.
The frame plates liner and impeller for type 4/3 C-AHR Slurry Pump have replaceable wear-resistant metal liners or rubber liners.
The shaft seals for 4/3 C-AHR Slurry Pump may be adoptable of gland seal , expeller seal or Mechanical seal . The discharge branch can be positioned at intervals of 45 degrees by request and oriented to any eight positions to suit installations and applications.
Bearing assembly use cylindrical structure, which helps adjust the space between impeller and cover plate liner easily, and being removed completely when being repaired. Bearings use grease lubrication. Here are the drive types, such as V belt drive, gear reducer drive, fluid coupling drive, and frequency conversion drive devices. Wide performance, good NPSH and high efficiency, the pump of this type may be installed in multistage series to meet the delivery for long distance.
Tobee® 4/3 C AHR Rubber Lined Slurry Pump Performance Parameters:
|
Model |
Max. Power (kw) |
Materials |
Clear water performance |
Impeller Vane No. |
|||||
|
Liner |
Impeller |
Capacity Q (m3/h) |
Head H (m) |
Speed n (rpm) |
Eff. η (%) |
NPSH (m) |
|||
|
30 |
Rubber |
Rubber |
79.2-180 |
5-34.5 |
800-1800 |
59 |
3-5 |
5 |
|
1.5/1B-AH, 2/1.5B-AH, 3/2C-AH, 3/2CC-AH, 4/3C-AH, 4/3CC-AH, 4/3D-AH, 4/3DD-AH, 6/4D-AH, 6/4DD-AH, 6/4E-AH, 6/4EE-AH, 8/6E-AH, 8/6EE-AH, 8/6F-AH, 8/6FF-AH, 8/6R-AH, 10/8ST-AH, 10/8F-AH, 10/8FF-AH, 12/10ST-AH, 12/10G-AH, 12/10F-AH, 12/10FF-AH, 14/12ST-AH, 14/12G-AH, 14/12FF-AH, 14/12F-AH, 16/14TU-AH, 20/18TV-AH
Tobee® 4/3 C-AHR Slurry Pump Application:
4/3 C-AHR Slurry Pump are widely used in mining, power, metallurgy, coal, deading, building material and other industrial lines to pump concentrate, tailings, sludge and other abrasive, high density slurries.
Minerals Flotation Processing
Electric Factory Coal Preparation
Coal Washing
Chemical Medium Processing
Effluent Handling
Sand And Gravel Handling
