Tobee® AH2x1.5B Abrasive Slurry Pumps are single-stage, single-suction, cantilevered, double casing, horizontal, centrifugal slurry pump. It is designed for conveying strong abrasive slurries in the mining, metallurgical, power, chemical, papermaking building material industry etc. Especially suitable for low flow, high concentration and high head working condition. 40-80% for higher density, strong abrasive slurries, 40-100% for medium density, medium abrasive slurries, 40-120% for lower density, lower abrasive slurries.
√ The Large diameter, slow turning, high efficiency impellers designed to achieve maximum wear life and lowest maintenance
√ The Large, open internal passages designed to reduce internal velocities, maximize wear life and lowest maintenance
√ Heavy duty construction with through-bolt design provides ease of maintenance and Min downtime
√ The Replaceable and Interchangeable wet end parts are lower the stocking cost, easy to repair and Min downtime
√ The Ductile iron fully lined casing provides durability, strength, safety, and long service life recommended while the Grey iron liner is the economic solution could meet the most customers required especially when you don’t need the pumps work at 24x7
√ Minimal shaft/impeller overhang reduces shaft deflection and increases packing life and the mean time between failures
√ Cartridge-style bearing assembly allows for maintenance in a clean environment without removal of the pump, resulting in reliable operation and prolonged bearing life, which is another way to increase the mean time between failures
√ Grease or oil lubrication bearing assembly options offer ease of maintenance and reduced downtime
√ Lower NPSH requirements results in enhanced hydraulic performance and extended the wear life
√ The metal or rubber parts are available for different work conditions Max the wear life and lowest the maintenance cost
Tobee® 2/1.5 B AH Slurry Pump Performance Parameters:
|
Model |
Max. Power (kw) |
Materials |
Clear Water Performance |
Impeller Vane No. |
|||||
|
Liner |
Impeller |
Capacity Q (m3/h) |
Head H (m) |
Speed n (rpm) |
Eff.η (%) |
NPSH (m) |
|||
|
15 |
Metal |
Metal |
32.4-72 |
6-58 |
1200-3200 |
45 |
3.5-8 |
5 |
|
Tobee® AH2x1.5B Abrasive Slurry Pump Structural Design:
Tobee® AH2x1.5B Abrasive Slurry Pump On-site Applications:
Tobee® TH2x1.5B Abrasive Slurry Pumps are designed for handling highly abrasive, high density slurries in metallurgy industry, mining industry, coal, power, chemical, building material and other industrial departments. The pumps of these models also can be installed as multi-stage series.
Accroding to different working condition, Tobee® slurry pumps can be use as minerals process pump, Booster sand pump, Dewatering Screen Pump, Tailings Pump, Metboom Pump, Feedprep Pump, Scavenger Feed Pump, Re-Cleaner Pump, Ball mill discharge Pump, Ruffer Feed Pump, Transfer to feedprep Pump, Metboom Return Pump, Thickner Underflow Pump, Thickner Tailings Pump, Thickner Underflow Pump, Rinse Pump, Dilute Pump, Re-Cleaner Pump, Rougher Feed Pump, Tailings booster Pump, Mill slurry Pump, Mill feed water Pump, Disc filter basin flushing Pump, Mixing tank slurry Pump, Gas cleaning slurry Pump, Windbox slurry Pump, Pellet hand scrubber slurry pump, Process recycle Pump, Scrubber slurry Pump, Prop pellets undersize Pump, Screen feeder Pump, Furn disch scrubber slurry Pump, Cosmetic recycle water Pump, Backwash Pump, Venturi scrubber slurry pump, Clarifier underflow pump, Pipeline transfer pump etc.
