DAM117C21 Shaft Spacers prove useful in drive assemblies to locate components and isolate the moving parts of ball bearings from adjacent components. So it is a important parts for 6x4D-AH slurry pump for operating.
Slurry Pump Shaft Spacer DAM117 is one of shaft seal parts in gland packing seal slurry pumps which fills a vacancy on the shaft between slurry pump shaft sleeve and impeller of 6/4D AH slurry pump, the Shaft Spacer acts as a limit to prevent any change in the distance or position between slurry pump parts and this is designed to increase interchangeability of shaft sleeve, so the Shaft Spacer of Slurry Pump is a important parts for slurry pump for operating.
Slurry pump shaft spacers are normally made in stainless steel, special materials are also available.
Our slurry pump shaft spacers are also available to suit:
AH slurry pumps, L slurry pumps, M slurry pumps, HH slurry pumps, G and GH slurry pumps, SP/SPR vertical slurry pumps, AF/AFR froth slurry pumps etc.
Shaft Spacer Parts Code: B117, C117, CAM117, D117, DAM117, E117, EAM117, F117, FAM117, S117, G117, T117, TH117
Technical requirements:
● Finish - Tumbled Finish
○ Spacers are tumble finished to provide a nice appearance
● Hole is chamfered on both ends -
○ To remove burrs
○ To make it easier to guide spacer onto bolt/screw/shaft/etc.
● Outer Diameter corners are chamfered lightly -
○ Tumble finish makes the OD chamfer into a radius
● SS420 alloy is best for:
○ Corrosion resistance,
○ Welding
