Name: 3/2D-HH High Head Slurry Pump with CV Drive Arrangement
Price: 5700.00 USD

3/2D-HH High Head Slurry Pump with CV Drive Arrangement

Product Brands: Tobee

3/2D-HH High Head Slurry Pump is designed to produce high heads per stage at high pressures. Commonly used for long distance transport lines, the high head slurry pump lines can often satisfy application duties with a single pump where others require multiple pumps in series.

price:

$5700.00 $5900.00

Pump model:

3/2D-HH

Seal Arrangement:

Packing seal Expeller seal Mechanical seal

H.S Code:

8413709990

Quantity:

- + (500 available)

Add to Favorite Items (0)

Sales: 0+

3/2D-HH High Head Slurry Pump is designed to produce high heads per stage at high pressures. Commonly used for long distance transport lines, the high head slurry pump lines can often satisfy application duties with a single pump where others require multiple pumps in series.

SPECIFICATIONS:

Size: 3" x 2"

Capacity: 68.4-136.8m3/h

Head: 25-87m

Speed: 850-1400rpm

NPSHr: 3-7.5m

Eff.: 47%

Power: Max. 60kw

Handling solids: 31mm

Materials: A05, A07, A12, A49, A51, A61 etc

Tobee® 3/2 D HH High Head Slurry Pump Design Features:

• High head, high pressure centrifugal end suction slurry pump design.
• Ductile iron fully lined casing provides durability, strength and long service life.
• Hyper wear resistance materials for longtime worklife.
• Multi-stage high pressure operation allowed.
• Heavy duty construction with through-bolt design provides ease of maintenance and results in less down time
• Large diameter, slow turning, high efficiency impellers result in maximum wear life and lower operating costs
• Large, open internal passages maximize wear life and lower operating costs
• Full flush gland, low flow, and dry running centrifugal seals reduce flush water usage minimizing pump operating costs.

Tobee® 3x2 HH High Head Slurry Pumps Performance Parameters:

Model

Max. Power

(kw)

Materials

Clear Water Performance

Impeller

Liner

Impeller

Capacity Q

(m3/h)

Head

(m)

Speed

(rpm)

Eff. η

(%)

NPSH

(m)

Vane No.

Impeller

Dia.

3/2D-HH

68.4-136.8

25-87

850-1400

3-7.5

457

Tobee^® HH High Head Slurry Pumps Applications:

HH high head slurry pumps widely used for wet crushers, SAG mill discharge, ball mill discharge, rod mill discharge, Ni acid slurry, coarse sand, coarse tailings, phosphate matrix, minerals concentrate, heavy media, dredging, bottom/fly ash, lime grinding, oil sands, mineral sands, fine tailings, phosphoric acid, coal, flotation, sugar beets, process chemical, pulp and paper, FGD, waste water etc.
