Name: 16/14 AH Centrifugal Slurry Pump FPL Insert H14041MA05A
Price: 5250.00 USD

16/14 AH Centrifugal Slurry Pump FPL Insert H14041MA05A

Product Brands: Tobee

H14041MA05A Frame Plate Liner Insert is one of spare parts for 16x14 AH Horizontal Slurry Pump.

price:

$5250.00 $5550.00

Parts Code:

TB-H14041MA05A

Materials:

A05A A05 A07 A49 A61

Pump model:

16/14TU-AH

Quantity:

- + (30 available)

Add to Favorite Items (48)

Sales: 10+

H14041MA05A Frame Plate Liner Insert is one of spare parts for 16x14 AH Horizontal Slurry Pump.

Slurry Pump Frame Plate Liner Insert is a wear part of slurry pumps, It is also called for slurry pump back liner based on locating position in slurry pump structure, Frame plate liner insert forms a pump chamber with throat bush and volute liner where the slurry would flow through them, Tobee offers frame plate liner inserts are interchangeable with warman pump frame plate liner inserts with high chrome, natural rubber, polyurethane for different working condition.

Slurry Pump Frame Plate Liner Insert Codes:

FPL Insert Code	AH Slurry Pumps	Materials
B1041	1.5/1B-AH	High chrome, Natural rubber, Polyurethane
B15041	2/1.5B-AH	High chrome, Natural rubber, Polyurethane
C2041	3/2C-AH	High chrome, Natural rubber, Polyurethane
D3041	4/3C-AH, 4/3D-AH	High chrome, Natural rubber, Polyurethane
E4041	6/4D-AH, 6/4E-AH	High chrome, Natural rubber, Polyurethane
F6041	8/6E-AH, 8/6F-AH, 8/6R-AH	High chrome, Natural rubber, Polyurethane
G8041	10/8ST-AH	High chrome, Natural rubber, Polyurethane
G10041	12/10ST-AH	High chrome, Natural rubber, Polyurethane
G12041	14/12F-AH,14/12ST-AH	High chrome, Natural rubber, Polyurethane
H14041	16/14TU-AH	High chrome, Natural rubber, Polyurethane
FPL Insert	HH Slurry Pumps	Materials
CH1041	1.5/1C-HH	High chrome, Polyurethane
DH2041	3/2D-HH	High chrome, Polyurethane
EH3041	4/3E-HH	High chrome, Polyurethane
FH4041	6/4F-HH	High chrome, Polyurethane
FH6041	6S-H, 8/6S-H	High chrome, Polyurethane
FPL Insert	L Slurry Pumps	Materials
175041	20A-L	High chrome, Natural rubber
32056	50B-L	High chrome, Natural rubber
43041	75C-L	High chrome, Natural rubber
64041	100D-L	High chrome, Natural rubber
86041	150E-L	High chrome, Natural rubber
108041	200E-L	High chrome, Natural rubber
SL30041	300S-L	High chrome, Natural rubber
SL35041	350S-L	High chrome, Natural rubber
STL40041	400ST-L	High chrome, Natural rubber
STL45041	450ST-L	High chrome, Natural rubber
TUL55041	550TU-L	High chrome, Natural rubber
FPL Insert	G(H) Gravel Pumps	Materials
DG4041	6/4D-G, 6/4E-G	High chrome
EG6041	8/6E-G	High chrome
FG8041	10/8F-G, 10/8S-G	High chrome
FG10041	12/10G-G	High chrome
GG12041	14/12G-G	High chrome
FGH8041	10/8F-GH	High chrome
SGGH10041	12/10G-GH	High chrome
TG14041	16/14TU-GH	High chrome
FPL Insert	SP Vertical Slurry Pumps	Materials
SP4041	40PV-SP	High chrome, Natural rubber, Polyurethane
SP65041	65QV-SP	High chrome, Natural rubber, Polyurethane
SP10041	100RV-SP	High chrome, Natural rubber, Polyurethane
SP15041	150SV-SP	High chrome, Natural rubber, Polyurethane
SP20041	200SV-SP	High chrome, Natural rubber, Polyurethane
SP25041	250TV-SP	High chrome, Natural rubber, Polyurethane
SP30041	300TV-SP	High chrome, Natural rubber, Polyurethane

Label: FPL Insert H14041MA05A 16x14TU-AH Pump FPL Insert Frame Plate Liner Insert H14041 for 16/14 16/14TU-AH Slurry Pump Wear Parts 16/14 AH Pump Spares Price
